Etage | Ratio | Couple nominal (Nm) |
Couple max (Nm) |
Vitesse nominale (tr/min) |
Vitesse max (tr/min) |
Force max radial (N) |
Force max axial (N) |
Jeu (Arcmin) |
Efficacité (%) |
Poids (kg) |
1 | 4 | 1300 | 2600 | 1500 | 3000 | 16000 | 13000 | 3 | 95 | 36 |
5 | 1100 | 2200 | 1500 | 3000 | 16000 | 13000 | 3 | 95 | 36 | |
7 | 800 | 1600 | 1500 | 3000 | 16000 | 13000 | 3 | 95 | 36 | |
10 | 460 | 920 | 1500 | 3000 | 16000 | 13000 | 3 | 95 | 36 | |
2 | 16 | 1300 | 2600 | 1500 | 3000 | 16000 | 13000 | 5 | 95 | 42 |
20 | 1300 | 2600 | 1500 | 3000 | 16000 | 13000 | 5 | 95 | 42 | |
25 | 1100 | 2200 | 1500 | 3000 | 16000 | 13000 | 5 | 95 | 42 | |
28 | 1300 | 2600 | 1500 | 3000 | 16000 | 13000 | 5 | 95 | 42 | |
35 | 1100 | 2200 | 1500 | 3000 | 16000 | 1300 | 5 | 95 | 42 | |
40 | 1300 | 2600 | 1500 | 3000 | 16000 | 1300 | 5 | 95 | 42 | |
50 | 1100 | 2200 | 1500 | 3000 | 16000 | 13000 | 5 | 95 | 42 | |
70 | 800 | 1600 | 1500 | 3000 | 16000 | 13000 | 5 | 95 | 42 | |
100 | 460 | 920 | 1500 | 3000 | 16000 | 13000 | 5 | 95 | 42 |
Taille | C1 | C2 | C3 | C4 | C5 | C6 | C7 | C8 |
HGH200-L1 (Single) | ⌀200 | 4-M12 | ⌀35/⌀38/⌀42 | 82,5 | ⌀114,3 | 8 | 180 | 211 |
⌀200 | 4-M12 | ⌀35/⌀42 | 117 | ⌀114,3 | 8 | 180 | 243,5 | |
⌀215 | 4-M12 | ⌀38/⌀42 | 87,5 | ⌀180 | 8 | 200 | 216 | |
HGH200-L2 (Double) | ⌀115 | 4-M8/4-M6 | ⌀22/⌀24 | 67,5 | ⌀95 | 8 | 115 | 259 |
⌀145 | 4-M8 | ⌀22/⌀24 | 72,5 | ⌀110 | 8 | 130 | 264 | |
⌀200 | 4-M12 | ⌀35/⌀38/⌀42 | 82,5 | ⌀114,3 | 6 | 180 | 274 | |
⌀200 | 4-M12 | ⌀35/⌀42 | 117 | ⌀114,3 | 8 | 180 | 306,5 | |
⌀215 | 4-M12 | ⌀38/⌀42 | 87,5 | ⌀180 | 8 | 200 | 279 |
